Connections and Setup | 3
19 Workstation Series User’s Guide
Buttons
The operation of the buttons consists of long or short presses depending on the
operation being performed. A button pressed for three (3) or more seconds is considered
a long press. A button pressed for less than three (3) seconds is considered a short
press.
The Stop/Resume button is positioned on the left side of the printer’s control panel and
the Feed/Cancel button is positioned on the right side. Together with the reset button on
the back of the printer, these buttons enable certain printer functions.
Note: Refer to the Operation section of this guide for more information about the
operational functionality of the buttons.
Feed
To position the label to the top-of-form, press the Feed/Cancel (right) button once the
media has been installed.
Test Labels
To print a test label from the printer, push the Stop/Resume button and the Feed/Cancel
button together with a short press. A quality label will print. This function can also be
performed with the configuration utility.
Calibration
The printer uses upper and lower top-of-form sensors to determine top-of-form. Both
sensors are transmissive and reflective to ensure top-of-form for qualified media. There
are two (2) types of calibrations:
• Paper Calibration
• Sensor Calibration
Paper Calibration
The printer should be calibrated after a new type of media has been installed or to verify
a paper out warning. When re-loading the same type of media, calibration should not be
necessary unless the printer does not find top-of-form.
1. Install the paper into the printer.
Green/Red
Combination
Fast Alternating Blink - Recovery mode
Slow Alternating Blink - Upgrade in progress
Slow Synchronized Blink - Cooling down or processing with a warning
Synchronized Double Blink - Power-up in progress
Light Printer State
