Overview | 2
9 Workstation Series User’s Guide
Specifications
Print Characteristics
Table 2: Print Characteristics
*Media wound out.
Dimensions and Weight
Table 3: Dimensions and Specifications
Environmental
Table 4: Temperatures
Print Driver Requirements
Table 5: Print Driver Minimum System Requirements
Variable Specifications
Print Resolution 300 dpi (11.8 dpmm)
Max Print Width 4.16” (105.7 mm)
Max Print Speed 4 ips (102 mmps)
Max Feed Speed 4 ips (102 mmps)
Max Back-up Speed 4 ips (102 mmps)
Media Width Range* 0.75” - 4.33” (19 mm - 110 mm)
Media Thickness Range* 0.003” - 0.008” (0.076 mm - 0.20 mm)
Print Length Range 0.25” - 30” (6.35 mm - 762 mm)
Height Width Depth Weight
6.02 in (15.3 cm) 6.75 in (17.1 cm) 8.32 in (21.1 cm) 3.1 lbs. (1.4 kg)
Temperature Humidity
Operating 32°F to 104°F (0°C to 40°C) <=20% to 80%
Storage -4°F to 140°F (-20°C to 60°C) <=35%
Minimum System Requirements
Processor / Speed 500 MHz processor
RAM 512 MB
Hard Drive Space 6 MB
