Table 6. AP25 Preset Formats
Name Source
Digital Cinema Digital In (1-16)
HDMI 1 HDMI Port 1
HDMI 2 HDMI Port 2
HDMI 3 HDMI Port 3
HDMI 4 HDMI Port 4
Nonsync1 Nonsync1
Nonsync2 Nonsync2
SPDIF S/PDIF 3 Dig
TOS A S/PDIF 1 Optical
TOS B S/PDIF 2 Optical
XD20 A Analog 8Chan
XD20 D Digital In (1-16)
2.8.2 Default EQ
The Default EQ appear in the Audio EQ Edit screen for Copy Preset to EQ. See a sample screen on page
79.
There is onl
y one option for Default EQ (Flat), which has EQ filters flat
, parametric filters disabled, and
Dirac optimization off
. Use this format as a starting point to create a new EQ set.
2.8.3 Default Channel Profiles
The Default Channel profile appears in the Audio Profile Edit screen for the Copy Default to Profile
option. Select Channel Profile > Edit Profiles > Copy Default to Profile and then select from the
dropdown menu Copy from Default. See a sample screen at 4.3.8.2 Edit Profiles, page 85.
There are two
default channel profiles: 6-channel and 8-channel.
The 6-channel profile assigns 6 channels as named in the table below and enables the VU meters for 6
channels.
Table 7. Default 6-Channel Profile
Channel Name
1 L
2 R
3 C
4 LFE
5 Ls
6 Rs
