B.7 COMMANDS THAT INITIATE DATA TRANSMISSIONS
The CHANNEL (CHN) and DUMP (DMP) commands, discussed in Section 5.a.1, are
the only ones that belong to this category—with the possible addition of VERSION
(VER), which causes a transmission of instrument "version" information to be issued
from the RS-23/485 Interface Port.
B.8 TABLE OF 3500 MNEMONIC COMMANDS
NOTE: Unless otherwise indicated, every command in the following list
applies equally to all 3500 Series conditioner models.
For the use of CONFIGURATION SETUP commands, see also Section 3.b. For
the use of CALIBRATION SETUP commands, see also Section 4.d. For the use
of RUN-TIME commands, see also Section 5.
AOG ANALOG OUTPUT GAIN
AOG=v [CMT]
Sets to v the ANALOG OUTPUT GAIN, where v is a percentage of full scale to the near-
est tenth of a percent between 74.4% and 125.6%. For RS-485 (only), returns ACK
[EOT].
AOG [CMT]
Reads current ANALOG OUTPUT GAIN. Returns v [EOT].
AOO ANALOG OUTPUT OFFSET
AOO=v [CMT]
Sets to v the ANALOG OUTPUT OFFSET, where v is a percentage of full scale to the
nearest tenth of a percent between -25.6% and 25.6%. For RS-485 (only), returns ACK
[EOT].
AOO [CMT]
Reads current ANALOG OUTPUT OFFSET. Returns v [EOT].
BAU BAUD RATE
BAU=b,s,d,p [CMT]
Sets BAUD RATE and other protocols for the RS-232/485 Interface Port: b = Baud rate:
1 = 300, 2 = 600, 3 = 1200, 4 = 2400, 5 = 4800, 6 = 9600, 7 = 19.2K, 8 = 38.4K, 9 = 153.6K;
s = No. of Stop Bits: 1 or 2; d = No. of Data Bits: 7 or 8; p = Parity: E = EVEN, O = ODD,
N = NONE, Z = ZERO. For RS-485 (only), returns ACK [EOT].
BAU [CMT]
Reads current protocol values for RS-232/485 Interface Port. Returns b,s,d,p [EOT].
BEE ZERO OFFSET
BEE=b [CMT]
Sets to b the ZERO OFFSET to be applied to the data reading, where -32700 ≤ b ≤
32700. For RS-485 (only), returns ACK [EOT].
IMPORTANT: THIS COMMAND SHOULD ONLY BE APPLIED WHEN THE 3500
INSTRUMENT IS SET FOR "TWO-POINT" OR "CALCULATED" CALIBRATION—THAT IS,
WHEN THE CAL=MXB [CMT] COMMAND IS IN EFFECT. IF ENTERED WHEN
CAL=LIN [CMT], UNPREDICTABLE READINGS COULD OCCUR.
BEE [CMT]
Reads current ZERO OFFSET. Returns b [EOT].
B.3
COMMAND AND RESPONSE SYNTAX
B
B.7 COMMANDS THAT INITIATE DATA TRANSMISSIONS B.8 3500 MNEMONIC COMMANDS
