Conditioner "r" Actual Input
Model value Range or Scale
3560 Voltage Conditioner 0.5V ±0.5 V-DC
1V ±1.0 V-DC
2V ±2.0 V-DC
5V ±5.0 V-DC
10V ±10.0 V-DC
20V ±20.0 V-DC
3570 DC Strain Gage Conditioner .75 0.75 mV/V
1.5 1.5 mV/V
3.0 3.0 mV/V
3578 AC Strain Gage Conditioner .75 0.75 mV/V
1.5 1.50 mV/V
3.0 3.00 mV/V
3.b.5 EXCITATION (MODELS 3570 AND 3578 ONLY)
EXCITATION (EXC): EXC=v [CMT]
Sets the excitation level to "v," as given by the following table:
Excitation No. ("v") Excitation
2 2 V (±1 V)
5 5 V (±2.5 V)
10 10 V (±5 V)
3.b.6 SENSITIVITY (MODEL 3540 ONLY)
SENSITIVITY (SEN): SEN=s [CMT]
Sets the input sensitivity range to "s," as given by the following table:
Sensitivity No. ("s") Sensitivity Range
.1 0.1 to 5 V
1 1 to 20 V
10 10 to 100 V
3.b.7 FILTER
RESPONSE (RES): RES=f [CMT]
Sets the analog filter corner to "f" Hz. For the Model 3540 Frequency Condi-
tioner, "f" = 2 (for 2.5), 5, or 10; for all other conditioners except the Thermo-
couple Conditioner, "f" = 5, 10, or 20. For the Model 3510 Thermocouple
Conditioner, the RES command is inactive— although an interrogation of
RES [CMT] will always answer "20."
FILTER (FIL): FIL=f [CMT]
Sets the digital filtering constant to "f" (where 0 ≤ f ≤ 9).
3.22
3
SETUP: INSTRUMENT CONFIGURATION
3.b CONFIGURING THROUGH THE RS-232/485 INTERFACE
