3.b.8 ANALOG OUTPUT
ANALOG OUTPUT OFFSET (AOO): AOO=v [CMT]
Sets the analog output offset to "v" (where v is a percentage of full scale to the
nearest tenth of a percent between -25.5% and 25.5%).
ANALOG OUTPUT GAIN (AOG): AOG=v [CMT]
Sets the analog output gain to "v" (where v is a percentage of full scale to the
nearest tenth of a percent between 74.5% and 125.5%).
See Section 3.a.7 for an explanation of the special use of the AOO and AOG para-
meters for the Model 3510 Thermocouple Conditioner.
3.b.9 LIMITS
HIGH LIMIT (HIL): HIL=h [CMT]
Sets the HIGH LIMIT value to "h."
HIGH HYSTERESIS (HHY): HHY=p [CMT]
Sets the HIGH HYSTERESIS window depth to "p" (where p is a percentage of
the existing SCALING FACTOR ("m") value to the nearest tenth of a percent).
HIGH LATCH (HLA): HLA=ON [CMT] or HLA=OFF [CMT]
Sets the HIGH-LIMIT LATCH status to "ON" or "OFF."
LOW LIMIT (LOL): LOL=L [CMT]
Sets the LOW LIMIT value to "L."
LOW HYSTERESIS (LHY): LHY=p [CMT]
Sets the LOW HYSTERESIS window depth to "p" (where p is a percentage of
the existing SCALING FACTOR ("m") value to the nearest tenth of a percent).
LOW LATCH (LLA): LLA=ON [CMT] or LLA=OFF [CMT]
Sets the LOW-LIMIT LATCH status to "ON" or "OFF."
3.b.10 TARE OFFSET
TARE REGISTER (TRR): TRR=v [CMT]
Sets the TARE REGISTER value to "v."
3.b.11 PRINT AND OUTPUT PARAMETERS
PRINT INTERVAL (PRI): PRI=t [CMT]
Sets the automatic print interval to approximately (t x 0.125) second(s), where
0 ≤ t ≤ 32700.
3.23
SETUP: INSTRUMENT CONFIGURATION
3
3.b CONFIGURING THROUGH THE RS-232/485 INTERFACE
