Most of the following ERROR CODES refer to the INTERNAL LINEARIZATION pro-
cedure discussed in Section 4.c.4.
Error Display Meaning
Err1 Insufficient input error—i.e., the desired display resolution
is too great for the input change.
Err2 Table entry error; the entered "input" is within the end-
points of another segment.
Err3 While calculating the "b" term of the segment, an arith-
metic overrange has occurred in justifying the decimal
points.
Err4 The current range is not legal for this instrument. Re-
enter the range.
Err5 The engineering-unit "output" entered for the current seg-
ment is equal to that of the previous segment (resulting in
a slope of "0").
Err6 The "input" of the current segment is equal to that of the
previous segment.
Err7 The entered "input" has an incorrect precision.
C.1
TABLE OF ERROR NUMBERS
C
TABLE OF ERROR NUMBERS
Appendix C
Table of Error Numbers
