DayTronic 3500 Series User Manual

LHY [CMT]
Reads current LOW HYSTERESIS window depth. Returns p [EOT].
LIM LIMITS
LIM=ON [CMT]
Includes LIMIT-STATUS Indicator Number in all transmissions from the RS-232/485
Interface Port in response to a CHANNEL (CHN) or DUMP (DMP) command. For
RS-485 (only), returns ACK [EOT].
LIM=OFF [CMT]
Cancels Limit-Status indication for CHN and DMP transmissions. For RS-485 (only),
returns ACK [EOT].
LIM [CMT]
Reads current Limit-Status indication status. Returns ON [EOT] or OFF [EOT].
LIN LINEARIZE
LIN=n,i,o [CMT]
Sets the effective endpoint of linearization Segment No. n, where "i" is the INPUT value
in millivolts, and "o" is the desired OUTPUT in desired engineering units. Not recog-
nized by the Model 3510 Thermocouple Conditioner. For RS-485 (only), returns
ACK [EOT].
LINn [CMT]
Reads the current INPUT/OUTPUT data for Segment No. n (0 ≤ n ≤ 15; it need not be
an "active" segment). Not recognized by the Model 3510 Thermocouple Condition-
er. Returns i,o [EOT].
LLA LOW LATCH
LLA=ON [CMT]
Sets the LOW LIMIT to LATCHING status. For RS-485 (only), returns ACK [EOT].
LLA=OFF [CMT]
Sets the LOW LIMIT to NONLATCHING status. For RS-485 (only), returns ACK [EOT].
LLA [CMT]
Reads current LOW-LIMIT LATCH status. Returns ON [EOT] or OFF [EOT].
LNR LINEARIZER RESET
LNR [CMT]
Resets the internal linearization table (see Section 4.c.4(a)); sets the active calibration
mode to "MXB" (see the CAL command). Not recognized by the Model 3510 Ther-
mocouple Conditioner. For RS-485 (only), returns ACK [EOT].
LNS LINEARIZATION SEGMENTS
LNS [CMT]
Reads the number of currently active linearization segments. Returns n [EOT], where
0 ≤ n ≤ 15, except for the Model 3510 Thermocouple Conditioner, which always
returns 0 [EOT].
LOL LOW LIMIT
LOL=L [CMT]
Sets the LOW LIMIT value to l (-32700 ≤ L ≤ 32700; L must be less than or equal to the
existing HIGH LIMIT (HIL) value). For RS-485 (only), returns ACK [EOT].
LOL [CMT]
Reads current LOW LIMIT value. Returns L [EOT].
B.7
COMMAND AND RESPONSE SYNTAX B
B.8 3500 MNEMONIC COMMANDS
