Fig. 23 shows the capture of successively lower-valued signal maxima. Here, it is
necessary to reset the "+PEAK" reading—to get it "back on track," so to speak—
somewhere along the rise of the input toward the second, lower-valued peak (P
2
).
This is done by returning the unit momentarily to "TRACK" MODE at time t
2
.
5.4
5
RUN-TIME OPERATION
5.b PEAK CAPTURE
P
1
ANALOG INPUT
P
2
t
0
t
1
t
2
t
3
t
4
TRACK + PEAK
+PEAK
READING
Fig. 22 Capture and Hold of Successively Higher-Valued Maxima
t
0
t
1
t
2
t
3
t
4
P
1
P
2
P
3
RESET
ANALOG
INPUT
+ PEAK
+PEAK READING
+ PEAK
Fig. 23 Capture and Hold of Successively
Lower-Valued Maxima Using Peak Reset
