G3
™
User’s & Installation Manual
7/October/2020
31
Figure 3.4b
While the FRONT antenna is selected, the down pointing arrow is illuminated
while tracking an approaching motor vehicle in moving opposite mode.
Figure 3.4c
While the REAR antenna is selected, the down pointing arrow is illuminated while
tracking a receding motor vehicle in moving opposite mode.
In moving opposite mode, the G3™ simultaneously processes and
displays the patrol and target motor vehicle speeds. Detected target
speeds will appear in the TARGET window. When no targets are
present, the TARGET window will show three dashes. Patrol speeds
will display in the PATROL window while the patrol motor vehicle is
moving.
3.5 Moving Mode Same Direction
To display the speed of targets traveling the same direction as the
patrol motor vehicle, use the Moving Mode Same Direction setting.
Figure 3.5a
A patrol car tracking a target using Moving Mode Same Direction.
To select this mode, press and release the MODE button until the
