G3
™
User’s & Installation Manual
7/October/2020
73
Appendix C: Menu Features
The menu feature allows the operator to ne tune some of the
settings of the radar. To activate the menu feature, press MENU
button.
Pressing OPTN steps through the menu items and the antenna
buttons change the settings. Pressing the MENU button again exits
the menu feature and saves the settings.
Feature
SENS
SQUELCH
DIM
BEEP
COMX
HARMONIC
VIP
HWY CTY
Setting
1-5
ON, OFF
AUTO, 1-8
ON,OFF
0- 5
ON, OFF
AUTO, MAN
ALL, CTY, HWY
Function
Range setting (sensitivity setting)
Toggles squelch setting on or o
Automatic or manual control of the
display LED brightness
Beep - Beeps when button is pushed
on the hand remote. Default is ON
Serial Port Communications Protocol
- Selects protocol for interfacing to
MDT, signs, etc.
If ON, radar will shohw "H" in center
target window during a harmonic
event. If set to OFF, radar will blank
a target speed during a harmonic
event.
VIP Auto or Manual mode
Choose CTY mode to help eliminate
combining during low speed patrol
use. Choose HWY mode to help
eliminate patrol shadowing during
higher speed patrol use. Choose ALL
setting for best performance in both
modes.
