G3
™
User’s & Installation Manual
7/October/2020
61
11.0 Specifications
11.1 Mechanical
Display Unit
Dimensions 13.3 cm x 3.68 cm x 1.8 cm
Weight 0.11 kg
Computer Unit
Dimensions 13.33 cm x 3.68 cm x 6.35 cm
Weight 0.45 kg
Hand-Held Remote
Dimensions 11.58 cm x 4.00 cm x 2.84 cm
Weight 0.68 kg
Ka-Band Directional Antenna
Dimensions 7.16 cm x 8.9 cm
Weight 0.25 kg
11.2 Antenna
Ka-Band Directional
IACP type VI
Nominal transmission frequency 35.500 GHz
Nominal horizontal beamwidth 12°
Polarization Circular
Nominal microwave power output 15mW
Maximum aperture power density < 2mW/cm
2
11.3 Environment
Ambient operating temperatures -30°C to +70°C
Maximum humidity 90% R.H.at 37°C
11.4 Power Consumption
Supply voltage range 10.8 to 16.5VDC
Low voltage threshold 10.8VDC
with visual indicator
