Figure 68. Removing a MicroSD card
Next steps
1 Install a MicroSD card.
2 Follow the procedure listed in After working inside your sled
Installing a MicroSD card
Prerequisites
1 Follow the safety guidelines listed in Safety Instructions.
2 Follow the procedure listed in Before working inside the sled.
NOTE
: To use an MicroSD card with your system, ensure that the Internal SD Card Port is enabled in System Setup.
NOTE: If reinstalling, ensure that you install the MicroSD cards into the same slots based on the labels you had marked
on the cards during removal.
Steps
1 Locate the MicroSD card slot on the IDSDM card. Orient the MicroSD card appropriately and place the contact-pin end of the card
into the slot.
NOTE
: The slot is keyed to ensure correct installation of the card.
2 Press the card into the card slot to lock it into their original location.
Installing and removing system components
95
