Dell 3335dn Service Manual

Locations and connections 5-7
J35 1 5 V dc Narrow media sensor - Engine Board
25 Vdc 5 Vdc
3 Ground
J12 1 5 V dc Thermistor - Engine Board
2 Ground
J13 1 0.6 V dc Toner level sensor - Engine Board
2 Ground
30 Vdc
J14 1 > 0 V dc 5 V dc Fuser exit sensor - Engine Board
25 Vdc
3 Ground
J17 1, 4 0.1 V dc 5 V dc Main gear drive motor - Engine Board
2, 3, 6 5 V dc
5 Ground
7, 8, 9 24 V dc
J19 USB port - Controller Board
J23 1 1.1 V dc 5 V dc Manual feed sensor - Engine Board
25 Vdc
3 Ground
J24 1 24 V dc MPF clutch - Engine Board
2 24 V dc 0 V dc
J25 1 24 V dc Manual feed solenoid - Engine Board
2 24 V dc 0 V dc
J34 1 24 V dc Media feed clutch - Engine Board
2 24 V dc 0 V dc
J27 1, 4 1.1 V dc 5 V dc Input and duplex sensor - Engine Board
2, 5 5 V dc
3, 6 Ground
J28 1, 4 3.3 V dc Tray 2 - Engine Board
2 24 V dc
6 Ground
J504 1 5 V dc Toner patch (density) sensor - Engine Board
31 Vdc 0 Vdc
4 Ground
5 5 Vdc 0Vdc
Connector Pin # Value
cable plugged
Value
cable unplugged
(if different)
Comments
