Replacing the speakers
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Using the alignment posts, place the right speaker on the palm-rest assembly.
2. Route the speaker cable through the routing guides on palm-rest assembly.
NOTE: Move the keyboard and keyboard-backlit cables out of the way.
3. Using the alignment posts, place the left speaker on the palm-rest assembly.
4. Adhere the tape that secures the speaker cable to the palm-rest assembly.
5. Replace the screw (M2x3) that secures the speaker to the palm-rest assembly.
Post-requisites
1. Replace the system board.
2. Replace the
heat-sink assembly.
3. Replace the battery.
4. Replace the coin-cell battery.
5. Replace the computer base.
6. Replace the
rear-I/O cover.
7. Replace the memory modules.
8. Replace the solid-state drive.
9. Replace the wireless card.
10.Replace the base cover.
40
