Removing the display back-cover and antenna
assembly
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
NOTE: These instructions are applicable only for laptops with a non-touch screen display.
1. Remove the base cover.
2. Remove the wireless card.
3. Remove the solid-state drive.
4. Remove the memory modules.
5. Remove the rear-I/O cover.
6. Remove the
computer base.
7. Remove the coin-cell battery.
8. Remove the heat-sink assembly.
9. Remove the battery.
10.Remove the
system board.
11. Remove the display assembly.
12. Remove the display bezel.
13. Remove the display panel.
14. Remove the display hinges.
15.Remove the
camera cable.
16.Remove the camera.
Procedure
After performing the steps in prerequisites we are left with the display back-cover and antenna assembly .
