Replacing the display hinges
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Align the screw holes on the display hinges with the screw holes on the display back-cover and antenna assembly.
2. Replace the eight screws (M2.5x2.0L) that secure the display hinges to the display back-cover and antenna assembly.
3. Route the antenna cables through the routing guides on the display back-cover and antenna assembly.
4. Route the logo-board cable through the routing guides on the display back-cover and antenna assembly.
5. Route the display cable through the routing guides on the display back-cover and antenna assembly.
6. Place the hinge caps on the display hinges and press down to snap them into place.
Post-requisites
1. Replace the
display panel.
2. Replace the display bezel.
3. Replace the display assembly.
4. Replace the system board.
5. Replace the
battery.
6. Replace the heat-sink assembly.
7. Replace the coin-cell battery.
8. Replace the computer base.
9. Replace the rear-I/O cover.
10.Replace the
memory modules.
11. Replace the solid-state drive.
12. Replace the wireless card.
13. Replace the base cover.
67
