CHAPTER 7: DRIVES
Lift the release panel and open the left side-panel.3.
Disconnect the power cable and the data cable from the back of the optical 4.
drive.
Pull the securing tab on the optical-drive bracket and slide the optical drive 5.
out through the front of the computer.
1
3
2
4
1 data cable 3 optical drive
2 power cable 4 securing tab
