CHAPTER 7: DRIVES
1
2
3
1 FlexBay cable 3 securing tab
2 Media Card Reader
Lift the release panel and open the left side-panel.3.
Disconnect the FlexBay cable from the back of the Media Card Reader.4.
Pull the securing tab on the FlexBay bracket and slide the Media Card 5.
Reader out through the front of the computer.
