Dell Alienware Area-51 - Removing and Replacing Hard Drives

042
042
/
CHAPTER 7: DRIVES
If you are removing a solid-state drive (SSD):4.
Remove the four screws that secure the SSD to the hard-drive bracket.a.
Slide and lift the SSD out of the hard-drive bracket. b.
2
1
3
1 screws (4) 3 SSD
2 hard-drive bracket
