13. Move the headset-port cable over the system board.
14. Connect the headset-port cable to the system board.
15. Move the I/O-board cable over the system board.
16. Connect the I/O-board cable to the system board.
17. Connect the left-fan cable to the system board.
18. Move the camera cable over the system board.
19. Connect the camera cable to the system board and close the latch.
20. Adhere the tape that secures the camera-cable connector latch to the system board.
Next steps
1. Install the heat pipe.
2. Install the left fan.
3. Install the right fan.
4. Install the headset port.
5. Install the power-adapter port.
6. Install the rear-I/O cover.
7. Install the battery.
8. Install the M.2 2230 solid-state drive.
9. Install the M.2 2280 solid-state drive.
10. Install the memory.
11. Install the base cover.
Fan and heat-sink assembly
Removing the fan and heat-sink assembly
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the rear-I/O cover.
5. Remove the power-adapter port.
6. Remove the headset port.
7. Remove the left fan.
8. Remove the right fan.
9. Remove the heat pipe.
10. Remove the system board.
About this task
CAUTION:
The heat sink may become hot during normal operation. Allow sufficient time for the heat sink to cool
before you touch it.
NOTE: For maximum cooling of the processor, do not touch the heat transfer areas on the heat sink. The oils in your skin
can reduce the heat transfer capability of the thermal grease.
The following image(s) indicate the location of the fan and heat-sink assembly and provides a visual representation of the
removal procedure.
58
Removing and installing components
