Removing the antenna
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the right-side cover.
2 Remove the wireless card.
Procedure
NOTE: Note the routing of white antenna cable and black antenna cable on
the chassis while removing them so that you can replace them correctly.
1 Lay the computer on the left side and remove the screw (M3x5) that secures
the antenna cables to the chassis.
2 Peel the tape that secures the antenna cables to the chassis.
3 Remove the screw (M3x5) and the tape that secures the antenna cables to the
chassis.
103
