Replacing the front-panel light
board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the front panel light-board cable to the slot on the chassis.
2 Replace the screw (M3x5) that secures the front panel light-board to the
chassis.
3 Connect the front panel light-board cable to the logo board.
4 Route the cables through the routing guides on the chassis and connect the
front panel light-board cable to the system board.
5 Place the computer in an upright position.
Post-requisites
1 Replace the front cover.
2 Replace the right-side cover.
47
