Replacing the slim optical drive
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align and snap the slim optical-drive bezel to the optical drive.
2 Place the slim optical-drive assembly on the slim optical-drive bracket and snap
the slim optical-drive assembly in place.
3 Slide the slim optical-drive assembly into the slim optical-drive bay through the
front of the computer.
4 Connect the data cable and power cable to the optical drive.
5 Place the computer in an upright position.
Post-requisites
1 Replace the front cover.
2 Replace the right-side cover.
31
