Dell EMC VxFlex Ready Node - Show Interface Output; Adapter Properties

Figure 26 Show interface output
In this example, index 17 is the appropriate network.
3. Type the command:
netsh interface ipv4 set subinterface <network_ID> mtu=9000
store=persistent
where, network_ID is the ID from the output in the previous step; in this case,
the ID is 17.
4. In the Advanced tab of the Adapter Properties dialog for your vendor and
driver, change the value of Jumbo Packet to 9000 , as illustrated in the
following figure:
Figure 27 Adapter properties
5. Click OK.
The network connection may disconnect briefly during this phase.
6. Verify that the configuration is working, by typing the command:
ping –f –l 8972 <Destination_IP_Address>
Output similar to the following should be displayed:
VxFlex OS performance fine-tuning
Dell EMC VxFlex Ready Node AMS User Guide 119
