Dell EMC VxFlex Ready Node - R630 Single-Node Server Configuration; R730 Xd Single-Node Server Configuration

Table 7 R730xd single-node server configuration (continued)
Description iDRAC
Monitoring
VxFlex OS
Data1
VxFlex OS
Client
Network
Port1
VxFlex OS
Client
Network
Port2
VxFlex
OS
Data2
VxFlex OS
Managemen
t Network
Not in Use
Speed 1 GbE 10 GbE 10 GbE 10 GbE 10 GbE 1 GbE 1 GbE
vSwitch N/A sio_vSwitch1 User allocated User allocated sio_vSwi
tch2
vSwitch0 N/A
VMkernel port vmk2 User
configurable
User
configurable
vmk3 vmk0 User
configurable
Physical
Switch
Mgmt Switch Switch 1 Switch 1 Switch 2 Switch 2 Mgmt Switch N/A
Note: The default supported slots for R730xd are slots 4 and 6, as shown in
figures Figure 4 on page 44 and Figure 5 on page 44.
Table 8 R630 single-node server configuration
Description iDRAC
Monitoring
VxFlex OS
Data1
VxFlex OS
Client
Network
Port1
VxFlex OS
Client
Network
Port2
VxFlex
OS
Data2
VxFlex OS
Managemen
t Network
Not in Use
Port iDRAC vmnic0 vmnic1 vmnic4 vmnic5 vmnic2 vmnic3
Physical Port
on node
iDRAC
(remote KVM)
Onboard 10G
(Left)
Onboard 10G
(Right)
PCI 10G
(Right)
PCI 10G
(Left)
Onboard 1G
(Left)
Onboard 1G
(Right)
Speed 1 GbE 10 GbE 10 GbE 10 GbE 10 GbE 1 GbE 1 GbE
vSwitch N/A sio_vSwitch1 User allocated User allocated sio_vSwi
tch2
vSwitch0 N/A
VMkernel port vmk2 User
configurable
User
configurable
vmk3 vmk0 User
configurable
Physical
Switch
Mgmt Switch Switch 1 Switch 1 Switch 2 Switch 2 Mgmt Switch N/A
Note: The expected slot location for the PCIe card is slot 3.
Server node port designations - Linux R630/R730xd servers
For single-node VxFlex Ready Node servers running on Linux, connect cables and
configure the ports as shown in the configuration tables, according to the server type.
The following additional information should be taken into account:
l
The logical bus address is dynamic and will be allocated by the operating system.
Use the slot name to correlate to between the bus address and port name of the
interface in the operating system.
l
In storage-only configurations, the customer ports can be used as additional data
ports.
Note:
When the AMS configures the data network ports in Linux, the interface
names used are sio_d_1 and sio_d_2.
Architecture
