Dell External M1000e t User Manual

Blade 2 I/O Module
B1 C1 C2 B2
Mezz3_Fab_C Port 10 Port 10
Mezz4_Fab_B Port 10 Port 10
Blade 3 I/O Module
B1 C1 C2 B2
Mezz1_Fab_C Port 3 Port 3
Mezz2_Fab_B Port 3 Port 3
Mezz3_Fab_C Port 11 Port 11
Mezz4_Fab_B Port 11 Port 11
Blade 4 I/O Module
B1 C1 C2 B2
Mezz1_Fab_C Port 4 Port 4
Mezz2_Fab_B Port 4 Port 4
Mezz3_Fab_C Port 12 Port 12
Mezz4_Fab_B Port 12 Port 12
Blade 5 I/O Module
B1 C1 C2 B2
Mezz1_Fab_C Port 5 Port 5
Mezz2_Fab_B Port 5 Port 5
Mezz3_Fab_C Port 13 Port 13
Mezz4_Fab_B Port 13 Port 13
Blade 6 I/O Module
B1 C1 C2 B2
Mezz1_Fab_C Port 6 Port 6
Mezz2_Fab_B Port 6 Port 6
Mezz3_Fab_C Port 14 Port 14
Mezz4_Fab_B Port 14 Port 14
Blade 7 I/O Module
B1 C1 C2 B2
Mezz1_Fab_C Port 7 Port 7
Mezz2_Fab_B Port 7 Port 7
42

Dell External M1000e t Specifications

General

Rack Units	10U
Model	M1000e
Power Supply	Up to 6 power supply units (PSUs)
Form Factor	Enclosure
Cooling	Redundant, hot-swappable fans
Management	Dell Chassis Management Controller (CMC)
Compatibility	Dell PowerEdge blade servers
Networking	Fibre Channel, InfiniBand
