Page #26 background imageLoading...
Page #26 background image
Deploying FCoE (FIP Snooping) on Dell Force 10 MXL
26
“show fip-snooping config”
Figure 20.
The Force10 MXL’s FIP-snooping FCF connection information can be checked by using:
show fip-snooping fcf. This command will display the FCF’s MAC address, the connecting interface and
applicable VLAN configured for the connection.
“show fip-snooping fcf” Figure 21.
The FCoE enabled connection to an enode or CNA in a host server can be checked by using:
show fip-snooping enode. This command will display the Enode MAC address, which port the Enode is
connected with, the FCF’s MAC address, the applicable VLAN configured for the connection and the FC-
ID.
“show fip-snooping enode Figure 22.
Using the Force10 MXL, the fip-snooping sessions can be validated using:
show fip-snooping sessions. This command will display the following items that are in an FCoE
session: Enode MAC address, Enode interface, FCF’s MAC address, FCF’s connecting interface, FCoE
VLAN being used, FCoE MAC addrss, FC-ID, Port WWPN, and Port WWNN being used for the session.
MXL-B1-Rack3015#show fip-snooping config
FIP Snooping Feature enabled Status: Enabled
FIP Snooping Global enabled Status: Enabled
Global FC-MAP Value: 0X0EFC00
FIP Snooping enabled VLANs
VLAN Enabled FC-MAP
---- ------- --------
1000 TRUE 0X0EFC00
MXL-B1-Rack3015# show fip-snooping fcf
FCF MAC FCF Interface VLAN FC-MAP FKA_ADV_PERIOD No.of Enodes
------- ------------- ---- ------ -------------- -----------
54:7f:01:23:45:67 Te 0/52 1000 0e:fc:00 8000 1
MXL-B1-Rack3015# show fip-snooping enode
Enode MAC Enode Interface FCF MAC VLAN FC-ID
--------- --------------- ------- ---- -----
5c:f9:12:34:56:78 Te 0/3 54:7f:01:23:45:67 1000 55:00:04
