Deploying FCoE (FIP Snooping) on Dell Force 10 MXL
43
Multiple port uplink (LAG) MXL configuration (can be copied and pasted) - continued
Figure 38.
NOTE: The commands should be entered in the order from the previous flowchart. The
running-config which is partially displayed in this figure shows were the entries occur but
not the proper order.
NOTE: The commands are in a different order for a multiple-link (port-channel/LAG)
configuration. If the ports to be added to the port-channel have current settings
configured including “portmode hybrid” and “switchport” these settings will need to be
removed. If they are not removed the configuration settings will not be successful.
interface Port-channel 5
no ip address
mtu 2500
portmode hybrid
switchport
fip-snooping port-mode fcf
no shutdown
interface Vlan 20
mtu 2500
!untagged TenGigabitEthernet 0/1-3
!untagged Port-channel 5
interface Vlan 1000
no ip address
mtu 2500
tagged TenGigabitEthernet 0/1-3
tagged Port-channel 5
fip-snooping enable
no shutdown
service-class dynamic dot1p
feature fip-snooping
fip-snooping enable
protocol lldp
