Dell Force10 MXL User Manual

Deploying FCoE (FIP Snooping) on Dell Force 10 MXL
64
Configuring the Dell Force10 MXL switch with connections to Cisco Nexus
vPC configuration with FCoE
Flowchart for MXL FCoE configuraton to Nexus vPC Figure 53.
Turn on FCoE
(fip-snooping
features) and
global settings
Connect to
switch
Configure downlink
server facing ports
feature fip-snooping
fip-snooping enable
protocol lldp
Service-class dynamic dot1p
interface range TenGigabitEthernet 0/1 – 0/32
portmode hybrid
switchport
protocol lldp
dcbx port-role auto-downstream
spanning-tree pvst edge-port
no shutdown
Configure uplink FCF
switch facing ports
interface range TenGigabitEthernet 0/43 – 0/44
port-channel-protocol LACP
port-channel 10 mode active
protocol lldp
no advertise dcbx-tlv ets-reco
dcbx port-role auto-upstream
no shutdown
default vlan-id 20
Configure VLAN interfaces
for switch and assign ports
interface Vlan 1000
tagged TenGigabitEthernet 0/1-52
fip-snooping enable
no shutdown
Configure default
VLAN for switch
Configure LAG/
PortChannel for FCoE
uplink to Cisco Nexus
interface port-channel 10
portmode hybrid
switchport
fip-snooping fcf
no shutdown
