Dell Force10 MXL

Deploying FCoE (FIP Snooping) on Dell Force 10 MXL
34
“show interfaces ets detail” - continued
Figure 31.
 After these validation steps, go into the disk management interface of the server. If the SAN is
configured appropriately the server will have an available LUN to use for storage.
Remote Parameters :
-------------------
Remote is enabled
TC-grp Priority# Bandwidth TSA
------------------------------------------------
0 0,1,2,4,5,6,7 50 % ETS
1 3 50 % ETS
2 - -
3 - -
4 - -
5 - -
6 - -
7 - -
15 - -
Remote Willing Status is disabled
Local Parameters :
------------------
Local is enabled
TC-grp Priority# Bandwidth TSA
------------------------------------------------
0 0,1,2,3,4,5,6,7 100% ETS
1 - -
2 - -
3 - -
4 - -
5 - -
6 - -
7 - -
15 - -
Oper status is init
ETS DCBX Oper status is Up with Mismatch
State Machine Type is Feature
Conf TLV Tx Status is enabled
23 Input Conf TLV Pkts, 7 Output Conf TLV Pkts, 0 Error Conf TLV Pkts
