Deploying FCoE (FIP Snooping) on Dell Force 10 MXL
32
The following command will show vital information on the ETS settings in the configuration. Type:
show interfaces ets detail. This command will show more specific detail about the ETS configuration
that has been negotiated between the devices. In this example interface TenGigabitEthernet 0/3 is
used as a downlink to a host server and CNA installed in that system. Interface TenGigabitEthernet
0/52 is the uplink into the top-of-rack FCF switch.
Some key items in these results will be TC-grp, Priority#, Bandwidth, and TSA. Note that only these two
interfaces are seen typically this command will list them all.
show interfaces ets detail” Figure 29.
MXL-B1-Rack3015# show interfaces ets detail
Interface TenGigabitEthernet 0/3
Max Supported TC Groups is 4
Number of Traffic Classes is 8
Admin mode is on
Admin Parameters :
------------------
Admin is enabled
TC-grp Priority# Bandwidth TSA
------------------------------------------------
0 0,1,2,3,4,5,6,7 100% ETS
1 - -
2 - -
3 - -
4 - -
5 - -
6 - -
7 - -
15 - -
Remote Parameters :
-------------------
Remote is enabled
TC-grp Priority# Bandwidth TSA
------------------------------------------------
0 0,1,2,4,5,6,7 50 % ETS
1 3 50 % ETS
2 - -
3 - -
4 - -
5 - -
6 - -
7 - -
15 - -
