20
| Printer Overview
Rear View
1 Phone Connector 6 "Blue" Plug
2 Wall Jack Connector 7 Duplex Unit
3 Ethernet Port 8 Fusing Unit
4USB Port 9Rear Cover
5 Power Connector
2
3
5
1
4
8
6
7
9
