Dell OptiPlex 3050 - Installing Chassis Frame

Installing chassis frame
1 Align and place the chassis frame on the display assembly.
2 Replace the M3 0.5x5 screws to secure the chassis frame to the display assembly.
3 Route the cables to the chassis frame.
4 Install the:
a system board
b graphics card assembly
c speaker
d OSD board
e system fan
f processor
g heat sink
h WLAN card
i SSD card
j coin cell battery
k memory module
l cable holder
m system board shield
n hard drive
o back cover
p optical drive
q stand
5 Follow the procedure in After working inside your computer.
