Dell OptiPlex 3050 User Manual

Technology and components
This chapter details the technology and components available in the systems.
Topics:
• Processors
• Chipsets
• Display options
• Intel HD Graphics
• Hard drive options
• USB features
• Memory features
• Realtek HD audio drivers
Processors
OptiPlex 3050 AIO system is shipped with Intel 6th generation and 7th generation core processor technology.
• Intel 6th Generation Core i5-6500T QC/ 6 MB/ 4T/ 2.5 GHz, 35 W(Support for Windows 7/8.1/10/Linux)
• Intel 6th Generation Core i7-6700T QC, 8 MB, 8T, 2.8 GHz, 35 W (Support for Windows 7/8.1/10/Linux)
• Intel 7th Generation Core i5-7500T QC/ 6 MB/ 4T/ 2.7 GHz, 35 W (Support for Windows 10/Linux Only)
• Intel 7th Generation Intel Core i7-7700T QC/ 8 MB/ 8T/ 2.9 GHz, 35W (Support for Windows 10/Linux Only)
NOTE
: The clock speed and performance varies depending on the workload and other variables. Total cache up to 8 MB cache
depending on processor type.
Skylake processor
Intel Skylake is the successor to the Intel® Broadwell processor. It is a microarchitecture redesign using an existing process technology and
it is branded as Intel 6th Gen Core. Like Broadwell, Skylake is available in four variants with suxes SKL-Y, SKL-H, SKL-U, and SKL-S.
The Skylake also includes Core i7, i5, i3, Pentium, and the Celeron processors.
Skylake specications
Table 1. Skylake
specications
Processor number Clock
Speed
Cache No. of cores/No. of
threads
Power Memory type Graphics
Intel 6th Generation Core
i5-6500T QC/ 6 MB/ 4T/
2.5 GHz, 35 W
2.50 GHz 6 MB 4/4 35 W DDR4-2133 Intel HD graphics
530
3
Technology and components 37

Dell OptiPlex 3050 Specifications

General

Bus type	DMI3
Stepping	S0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i3-7100
System bus rate	8 GT/s
Processor family	Intel® Core™ i3
Processor socket	LGA 1151 (Socket H4)
Processor threads	4
Processor codename	Kaby Lake
Processor frequency	3.9 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	51 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory clock speeds supported by processor	1333, 1600, 2133, 2400 MHz
Maximum internal memory supported by processor	64 GB
Chassis type	SFF
Product color	Black
Cable lock slot	Yes
Placement supported	Horizontal/Vertical
Audio chip	Realtek ALC3234
Product type	PC
Market positioning	Business
Password protection type	BIOS, Supervisor, User
Compatible processor series	Intel Celeron, Intel Pentium
Memory slots	2x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	2400 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Optical drive type	DVD±RW
Card reader integrated	-
Total storage capacity	128 GB
On-board graphics card ID	0x5912
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 630
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1100 MHz
Number of displays supported (on-board graphics)	3
Trial software	Microsoft Office
Operating system language	Multilingual
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power supply	180 W
Power supply input voltage	90 - 264 V
Power supply input frequency	47/63 Hz
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	AC
Scalability	1S
Processor code	SR35C
Processor ARK ID	97455
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2015C
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	292 mm
Width	92.7 mm
Height	290 mm
Weight	5140 g
