Installing the speaker cover
1 Align the speaker cover to its position on the back of the computer.
2 Tighten the screws to secure the speaker cover to the computer.
3 Install the:
a back cover
b cable cover
c stand
4 Follow the procedure in After Working Inside Your Computer.
Hard drive
Removing the hard drive assembly
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a stand
b back cover
3 To remove the hard drive assembly:
a Press the tab on the bracket, and slide the hard-drive assembly until the tabs are released from either side of the assembly [1].
b Slide the hard-drive assembly upwards to remove it from the computer [2].
14
Removing and installing components
