Installing the VESA mount bracket
1 Align and place the bracket in the slot on the computer.
2 Tighten the screws that secure the VESA mount bracket to the computer.
3 Install the:
a power supply unit
b system board shield
c speaker cover
d cable cover
e back cover
f stand
4 Follow the procedure in After working inside your computer.
Converter board
Removing the converter board
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a stand
b back cover
c cable cover
d speaker cover
e system board shield
f power supply unit
28
Removing and installing components
