Dell OptiPlex 5250 - Memory Module; Removing the Memory Module; Installing the Memory Module

3 Follow the procedure in After working inside your computer.
Memory module
Removing the memory module
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a stand
b back cover
c system board shield
3 To remove the memory module:
a Pry the retention clips away from the memory module until it pops up [1].
b Lift the memory module from the connector [2].
Installing the memory module
1 Insert the memory module on the memory connector until the clips secure the memory module.
2 Install the:
a system board shield
b back cover
c stand
3 Follow the procedure in After working inside your computer.
18
Removing and installing components
