7. Follow the procedure in after working inside your computer.
Memory
Removing the memory
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the side cover.
3. Remove the 2.5-inch hard-drive.
4. Remove the 3.5-inch hard-drive.
5. Remove the hard-drive and optical-drive cage.
About this task
The following images indicate the location of the memory modules and provide a visual representation of the removal procedure.
Steps
1. Carefully spread apart the securing-clips on each end of the memory-module slot.
2. Grasp the memory module near the securing clip, and then gently ease the memory module out of the memory-module slot.
CAUTION:
To prevent damage to the memory module, hold the memory module by the edges. Do not touch
the components on the memory module
NOTE: Repeat step 1 to step 2 to remove any other memory modules installed in your computer.
NOTE: Note the slot and the orientation of the memory module in order to replace it in the correct slot.
Installing the memory
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
Removing and installing components
51
