Dell P29E - Installing the Hard Drive; Removing the Keyboard

b. battery
3. Perform the following steps as shown in the illustration:
a. Remove the screws that secure the hard drive to the computer [1].
b. Lift the hard-drive latch to the unlock position [2].
c. Slide and lift the hard drive from the computer [3].
4. Remove the screws that secure the hard drive. Lift the hard drive from the bracket.
Installing the hard drive
1. Tighten the screws to secure the hard drive to the hard-drive bracket.
2. Insert the hard drive into its slot in the computer.
3. Tighten the screws to secure the hard drive to the computer.
4. Install the:
a. battery
b. battery cover
5. Follow the procedure in After working inside your computer
Removing the keyboard
1. Follow the procedures in Before working inside your computer.
2. Remove the:
a. battery cover
b. battery
c. hard drive
13
