Dell P29E - Installing the Display Bezel; Removing the Camera

Installing the display bezel
NOTE: The display bezel is available only for non touch systems.
1. Place the display bezel on the display assembly.
2. Press the edges of the display bezel until it clicks onto the display assembly.
3. Install the:
a. display assembly
b. palmrest
c. keyboard
d. hard drive
e. base cover
f. battery
g. battery cover
4. Follow the procedure in After working inside your computer.
Removing the camera
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. battery cover
b. battery
c. base cover
d. hard drive
e. keyboard
f. palmrest
g. display assembly
h. display bezel
3. Perform the following steps as shown in the illustration.
a. Disconnect the camera cable from the computer [1].
b. Remove the camera module from the computer [2].
