Installing the WLAN Card
1. Insert the WLAN card in its slot in the computer.
2. Route the antenna cables through the routing channel and connect them to the WLAN card.
3. Align the shield and tighten the screw to secure the WLAN card to the computer.
4. Install the:
a. base cover
b. battery
c. battery cover
5. Follow the procedures in After working inside your computer
Removing the M.2 Solid State Drive (SSD)
1. Follow the procedures in Before working inside your computer.
2. Remove the:
a. battery cover
b. battery
c. base cover
3. Perform the following steps as shown in the illustration:
a. Remove the screw that secures the shield to the computer.
b. Remove the shield from the computer.
c. Remove the screw that secures the M.2 SSD to the computer.
d. Remove the M.2 SSD away from the computer.
