Installing the coin cell battery
1. Replace the coin cell battery in its slot in the computer.
2. Connect the coin cell battery cable.
NOTE: Ensure that the coin cell battery cable does not protrude outside its compartment.
3. Install the:
a. base cover
b. battery
c. battery cover
4. Follow the procedure in After working inside your computer.
Removing the hard drive cable
1. Follow the procedures in Before working inside your computer.
2. Remove the:
a. battery cover
b. battery
c. base cover
d. hard drive
3. Remove the screws that secure the hard drive connector to the system board and remove it from the computer.
20
