Dell P34E - Page 22

2. To install the 4-cell battery:
a. Place the battery onto its slot in the system [1 , 2].
b. Replace the 2 (M2.5x3.0) screws to secure the battery to the system [3].
c. Connect the battery cable to the connector in the system board [4].
22
Removing and installing components
