712 Configuring L2 Multicast Features
• Unit and Ports — Displays and assigns multicast group membership to
ports. To assign membership, click in
Static for a specific port. Each click
toggles between S, F, and blank. See Table 25-2 for definitions.
•
LAGs — Displays and assigns multicast group membership to LAGs. To
assign membership, click in
Static for a specific LAG. Each click toggles
between S, F, and blank. See Table 25-2 for definitions.
Tab le 25 -2
contains definitions for port/LAG IGMP management settings.
Adding and Configuring Bridge Multicast Address Groups
To configure a bridge multicast group:
1
From the Bridge Multicast Group page, click Add .
The
Add Bridge Multicast Group page displays.
Table 25-2. Port/LAG IGMP Management Settings
Port Control Definition
D Dynamic: Indicates that the port/LAG was dynamically joined to
the Multicast group (displays in the
Current row).
S Static: Attaches the port to the Multicast group as a static member
in the Static row. Displays in the Current row once Apply is clicked.
F Forbidden: Indicates that the port/LAG is forbidden entry into the
Multicast group in the Static row. Displays in the Current row once
Apply is clicked.
Blank Blank: Indicates that the port is not attached to a Multicast group.
