Hardware Overview 91
LED Definitions
This section describes the light emitting diodes
(LEDs) on the front panel of
the switch and on the optional modules that plug into the back panel.
Port LEDs
Each port on a PowerConnect 7000 Series switch includes two LEDs. One
LED is on the left side of the port, and the second LED is on the right side of
the port. This section describes the LEDs on the switch ports, Out-of-Band
(OOB) management port, and console port.
100/1000/10000Base-T Port LEDs (PC7024, PC7024F, PC7048, PC7048R)
Table 3-1 contains the 100/1000/10000Base-T port LED definitions for the
PowerConnect 7024, PowerConnect 7048, and PowerConnect 7048R, as well
as the PowerConnect 7024F Combo ports.
100/1000/10000Base-T Port LEDs (PC7024P and PC7048P)
The 100/1000/10000Base-T ports on the PowerConnect 7024P and
PowerConnect 7048P include Power over Ethernet Plus support, and each
port is capable of delivering up to 30W of power to the connected PoE-
powered device.
Table 3-2 contains the 100/1000/10000Base-T port LED definitions for the
PowerConnect 7024P and PowerConnect 7048P.
Table 3-1. 100/1000/10000Base-T Port LED Definitions (Non-PoE Plus Models)
LED Color/Activity Definition
Left Green The port is operating at 1000 Mbps.
Yellow The port is operating at 10/100 Mbps.
Solid A link is present.
Off No link is present.
Right Green blinking The port is active.
Off The port has no activity.
