22 | Installing AWMS Dell PowerConnect W AirWave 7.1 | User Guide
AWMS Navigation Basics
Every AWMS page contains three basic sections, as follows:
Status Section
Navigation Section
Activity Section
The AWMS pages also contain Help
links with GUI-specific help information and certain standard action
buttons. illustrates these sections.
25 TCP SMTP Support email (optional) > AirWave support email server
49 UDP TACACS AWMS Administrative
A
uthentication
> Cisco TACACS+
53 UDP DNS DNS lookup from AWMS > DNS Server
69 UDP TFTP Transfer configuration files or FW < APs or controllers
80 TCP HTTP Configure devices > Legacy APs
80 TCP HTTP Firmware upgrades < Colubris devices
80 TCP VTUN Support connection (optional) > AirWave support home office
161 UDP SNMP Get and Set operations > APs or controllers
162 UDP SNMP Traps from devices < APs or controllers
162 UDP SNMP Traps from AWMS > NMS
443 TCP HTTPS Web management < Laptop or workstation
443 TCP HTTPS WLSE polling > WLSE
443 TCP VTUN Support connection (optional) > AirWave support home office
1701 TCP HTTPS AP and rogue discovery > WLSE
1741 TCP HTTP WLSE polling > WLSE
1813 UDP RADIUS Retrieve client authentication
info
< Accounting Server
1813 UDP RADIUS Retrieve client authentication
info
< AP or controllers
1813 UDP RADIUS Outbound from AWMS to a
RADIUS
server for AWMS
administrator authentication
> RADIUS server
2002 TCP HTTPS Retrieve client authentication
info
> ACS
5050 UDP RTLS Real Time Location Feed < Aruba thin APs
8211 UDP PAPI Real Time Feed < >
WLAN switches
ICMP Ping Probe > APs or controllers
Table 4 AWMS Protocol and Port Chart (Continued)
Port Type Protocol Description
Dataflow
Direction
Device Type
To Next Page
