Dell PowerEdge XR4000w - Page 14

Table 11. M.2 Support Thermal Limitation for XR4000z Chassis (NAF Configurations)
M.2 Type M.2 Module (Witness Sled)
Edge 2 (Max 55°C) Edge 1 (Max 50°C) ASHRAE A4 (Max 45°C)
Micron 480GB No No No
Micron 800GB No No No
Micron 960GB Not Supported Not Supported Yes
Micron 1.92TB No No No
Micron 3.84TB No No No
Hynix 480GB No No No
Hynix 800GB No No No
Hynix 960GB Not Supported Not Supported Yes
Hynix 1.92TB No No No
Hynix 3.84BT No No No
Table 12. XR4000w Processor Support Thermal Limitation for XR4000r chassis (NAF Configurations)
Processor Type HSK type Fan type
NAF Configurations
Edge 2 (Max
55°C)
Edge 1 (Max
50°C)
ASHRAE A4 (Max
45°C)
Intel Atom C3508, 4 cores, 11.5W
Aluminum
extrusion
Fan Not Supported Yes
Thermal Restrictions
ASHRAE A4 Support Restriction for RAF (Reverse Air Flow Direction) Configurations
● In redundant mode, two power supplies are required. A single power supply failure is not supported.
Edge1 Support Restriction RAF (Reverse Air Flow Direction) Configurations
● In redundant mode, two power supplies are required. A single power supply failure is not supported.
Edge2 Support Restriction RAF (Reverse Air Flow Direction) Configurations
●
In redundant mode, two power supplies are required. A single power supply failure is not supported.
ASHRAE A4 Support Restriction NAF (Normal Air Flow Direction) Configurations
● In redundant mode, two power supplies are required. A single power supply failure is not supported.
14
Technical specifications
