Thermal restriction matrix

Table 7. M.2 Support Thermal Limitation for XR4000r Chassis (RAF Configurations)

M.2 Type M.2 Module (Witness Sled)

Edge 2 (Max 55°C) Edge 1 (Max 50°C) ASHRAE A4 (Max 45°C)

Micron 480GB No No No

Micron 800GB No No No

Micron 960GB Yes Yes Yes

Micron 1.92TB No No No

Micron 3.84TB No No No

Hynix 480GB No No No

Hynix 800GB No No No

Hynix 960GB Yes Yes Yes

Hynix 1.92TB No No No

Hynix 3.84BT No No No

Table 8. M.2 Support Thermal Limitation for XR4000z Chassis (RAF Configurations)

M.2 Type M.2 Module (Witness Sled)

Edge 2 (Max 55°C) Edge 1 (Max 50°C) ASHRAE A4 (Max 45°C)

Micron 480GB No No No

Micron 800GB No No No

Micron 960GB Yes Yes Yes

Micron 1.92TB No No No

Micron 3.84TB No No No

Hynix 480GB No No No

Hynix 800GB No No No

Hynix 960GB Yes Yes Yes

Hynix 1.92TB No No No

Hynix 3.84BT No No No

Table 9. XR4000w Processor Support Thermal Limitation for XR4000r chassis (RAF Configurations)

Processor Type HSK type Fan type

XR4000 RAF Configurations

Edge 2 (Max

55°C)

Edge 1 (Max

50°C)

ASHRAE A4 (Max

45°C)

Intel Atom C3508, 4 cores, 11.5W

Aluminum

extrusion

Fan Yes Yes Yes

Table 10. XR4000w Processor Support Thermal Limitation for XR4000z chassis (RAF Configurations)
