Table 1. S4048ON LED behavior(continued)
LED Description
Flashing amberPower supply warning event; power
continues to operate.
LOCATOR LED
OffLocator function is disabled.
Flashing blueLocator function is enabled.
Table 2. Management Ethernet port LEDs
LED Description
Link LED
OffNo Link
Solid greenLink on 1 Gbps speed
Solid yellowLink on 10/100 Mbps speeds
Table 3. SFP+ port LEDs
LED Description
Link LED
OffNo Link
Solid greenLink on 10 Gbps speed
Solid amberLink on 1 Gbps speed
Activity LED
OffNo Link
Blinking greenTransmit/receive is active.
Table 4. Default 1x40G mode QSFP+ port LEDs
LED Description
Link/Activity LED
OffNo Link
Solid greenLink operating at maximum speed40 Gbps
Flashing greenLink activity at maximum speed40
Gbps
Flashing amberone second on and one second offport
beacon
Table 5. 4x10G mode QSFP+ port LEDs
LED Description
Link/Activity LED
OffNo Link
Solid amberLink operating at lower or 10 Gbps speed
Flashing amberLink activity at lower or 10 Gbps speed
Flashing amberone second on and one second offport
beacon
Prerequisites
The following is a list of components that are required for successful installation of the S4048-ON.
NOTE: Detailed installation instructions for the S4048-ON are provided in Site Preparations and Install the S4048ON.
S4048ON chassis or multiple chassis, if stacking
AC country- and regional-specific cables to connect the AC power source to each of the chassis AC power supplies
Mounting brackets for rack installation, included
Screws for rack installation
#1 and #2 Phillips screwdrivers, not included
Torx screwdriver, not included
Ground cable screws, included
10
The S4048ON switch

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell PowerSwitch S4048-ON and is the answer not in the manual?

Dell PowerSwitch S4048-ON Specifications

General IconGeneral
Switching Capacity1.44 Tbps
AirflowFront-to-back or back-to-front
ManageableYes
Total Number of Network Ports54
Uplink Port6 x 40GbE QSFP+
Number of 40 Gigabit Ethernet Ports6
Number of 10 Gigabit Ethernet Ports48
Media Type SupportedOptical Fiber, Twisted Pair
Ethernet Technology10 Gigabit Ethernet, 40 Gigabit Ethernet
Layer SupportedLayer 2, Layer 3
Form FactorRack-mountable
Operating Temperature32 °F to 104 °F (0 °C to 40 °C)
Power SupplyDual, hot-swappable
Dimensions1.7 inches
Product TypeLayer 3 Switch
Port/Expansion Slot Details48 x 10GbE SFP+, 6 x 40GbE QSFP+
Network Technology40GBase-X
Input Voltage100-240 VAC
Height1.7 inches
Width17.3 inches
Ports48 x 10GbE, 6 x 40GbE
Weight24.5 lbs
